AUO C080EAN04.1 Application Details
| Basic Detail : |
Manufacturer |
AUO |
Model Name |
C080EAN04.1 |
| Panel Type |
a-Si TFT-LCD , LCM |
Another Name |
|
| Panel Size |
8.0” |
Designed For |
Automotive Display |
| Maximum Ratings : |
OP Temperature |
-30 ~ 85 °C |
ST Temperature |
-40 ~ 95 °C |
| RoHS |
RoHS |
Vibration Level |
2.9G (28.4 m/s²) |
| Features : |
Wide Temperature, 3G Vibration，Hight Brightness，WLED Backlight,U/D,L/R Reverse，Matte |
AUO C080EAN04.1 Optical Details
| Basic Information : |
Luminance |
750 cd/m² (Typ.) |
Contrast Ratio |
1000 : 1 (Typ.) (Transmissive) |
| Good View at |
Symmetry |
Response Speed |
20 (Max.)(Tr+Tf) |
| Viewing Angle |
80/80/80/80 (Typ.)(CR≥10) |
Operating Mode |
AHVA, Normally Black, Transmissive |
| Color Performance : |
Chromaticity |
X:0.317; Y:0.315 |
Display Colors |
16.7M (8-bit) |
Color Temperature |
6376K |
White Variation |
1.25 (Max.)(9 points) |
| 1931 Color Gamlt : |
NTSC Ratio |
68% |
sRGB |
90% coverage |
| Adobe RGB |
70% coverage |
DCI-P3 |
71% coverage |
| Rec.2020 |
51% coverage |
Remarks |
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Dispaly Performance : |
Outdoor Visibility |
Sunlight Readable |
Transmissivity |
- |
AUO C080EAN04.1 Mechanical Details
| Pixel Features : |
Number of Pixel |
1280(RGB)×720, WXGA |
Arrangement |
RGB Vertical Stripe |
| Dot Pitch (mm) |
0.046×0.138 (H×V) |
Pixel Pitch(mm) |
0.138×0.138 (H×V) [184PPI] |
| Physical Size : |
Active Viewing(mm) |
176.64(H) × 99.36(V) |
Bezel Area (mm) |
179.55(H) × 105.36(V) |
| Outline Dim.(mm) |
186.5(H) × 117.12(V) |
Depth(mm) |
7.2 (Typ.) |
| Outline Features : |
Form Style |
Flat Rectangle |
Outline Shape |
|
| Aspect Ratio |
16:9 (H:V) |
Orientation |
Landscape type |
| Mounting : |
Without |
| Other Spec : |
Weight |
229±23g |
Treatment |
Antiglare |
AUO C080EAN04.1 Electronics Details
| Refresh Rate : |
60Hz |
| Reverse Scan : |
Yes (U/D, L/R) |
AUO C080EAN04.1 Interface Detail
| Signal Electrical : |
Signal Interface |
LVDS (1 ch, 8-bit) |
Logic Voltage |
- |
| Signal Electrical : |
Voltage Input |
3.3/13.5/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
Current Input |
40/17/1/1mA (Typ.)(IDD/AIDD/IGH/IGL) |
| Interface Features : |
Position |
- |
Physical Type |
FPC |
| Interface Detail : |
Brand |
Model |
Pin Pitch |
Pins |
Amount |
Pin Assignment |
| |
|
0.5mm |
40 pins |
1 pcs |
|
AUO C080EAN04.1 Backlight Details
| Lamp Features : |
Lamp Type |
WLED |
Quantity |
6S4P |
Position |
Edge light type |
| Exchange |
- |
Lamp Shape |
4strings |
Lamp Life |
30K(Min.) (Hours) |
| Lamp Electrical : |
Input Voltage |
16.2/18.6/20.4V (Min./Typ./Max.) |
Input Current |
80/85mA (Typ./Max.) |
| Consumption |
5.95W (Typ.) |
| Interface Features : |
Position |
- |
Physical Type |
FPC |
| Interface Detail : |
Brand |
Model |
Quantity |
Pins |
Pitch |
Pin Configuration |
| |
|
1 pcs |
10 pins |
1.0 mm |
|
| Backlight Driver : |
No |
AUO C080EAN04.1 Packing Details
| Package Box : |
Amount |
Weight |
Size (L×W×H) |
| 52 pcs / box |
TBD |
550×350×250 mm |
