AUO C090EAN02.0 Application Details
| Basic Detail : | Manufacturer | AUO | Model Name | C090EAN02.0 |
| Panel Type | a-Si TFT-LCD , LCM | Another Name | Automotive Display | |
| Panel Size | 9.0” | Designed For | Automotive Display,Outdoor High Brightness | |
| Maximum Ratings : | OP Temperature | -30 ~ 85 °C | ST Temperature | -40 ~ 95 °C |
| RoHS | RoHS | Vibration Level | 2.9G (28.4 m/s²) | |
| Features : | Srgb,Wide Temperature,3G Vibration, Hight Brightness，WLED Backlight,Matte，U/D,L/R Reverse | |||
AUO C090EAN02.0 Optical Details
| Basic Information : | Luminance | 650cd/m² (Min.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
| Good View at | Symmetry | Response Speed | 20/20 (Typ.)(Tr+Td) (ms) | |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Operating Mode | AHVA, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.296; Wy:0.313 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 7749K | White Variation | 1.25 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 72% | sRGB | 100% coverage |
| Adobe RGB | 75% coverage | DCI-P3 | 74% coverage | |
| Rec.2020 | 53% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
AUO C090EAN02.0 Mechanical Details
| Pixel Features : | Number of Pixel | 1280(RGB)×720 [WXGA] | Arrangement | RGB Vertical Stripe |
| Dot Pitch(W×H) | 0.05175×0.15525 (H×V) | Pixel Pitch(mm) | 0.15525×0.15525 (H×V) [163PPI] | |
| Physical Size : | Active Viewing(mm) | 198.72(H) × 111.78(V) | Bezel Area (mm) | 202.02(H) × 114.74(V) |
| Outline Dim.(mm) | 210(H) × 126.8(V) | Depth(mm) | 7.7/9.7 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9(H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | TBD | Treatment | Antiglare |
AUO C090EAN02.0 Electronics Details
| Refresh Rate : | 60Hz |
| Reverse Scan : | Yes (U/D, L/R) |
AUO C090EAN02.0 Interface Detail
| Signal Electrical : | Voltage Supply | 3.3/13.5/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) | Current Supply | - |
|||||
| Signal Voltage | - |
Signal Interface | LVDS (1 ch, 8-bit) | ||||||
| Interface Features : | Position | - | Physical Type | FPC | |||||
| Interface Detail : | Brand |
Model | Pin Pitch | Pins | Amount | Pin Assignment | |||
| 60 pins | 1 pcs | ||||||||
AUO C090EAN02.0 Backlight Details
| Lamp Features : | Lamp Type | WLED | Quantity | 7S3P | Position | Edge light type | ||||||
| Exchange | - |
Lamp Shape | 3strings | Lamp Life | 10K(Min.) (Hours) | |||||||
| Lamp Electrical : | Input Voltage | 23.8V (Max.) | Input Current | 80mA (Typ..) | ||||||||
| Consumption | 5.71W (Max.) | |||||||||||
| Interface Features : | Position | - | Physical Type | FPC |
||||||||
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment | ||||||
| 0.5mm | 10pins | 1 pcs | BLE-10PINS-NAAANNCCCN |
|||||||||
| Backlight Driver : | No | |||||||||||
AUO C090EAN02.0 Carton Details
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
| 15 pcs / box | 15 Kgs | 520×340×250 mm (L×W×H) |
