AUO G057VCE-TH1 Application Details
Basic Info : |
Panel Brand |
AUO |
Panel Model |
G057VCE-TH1 |
Diagonal Size |
5.7inch |
Application |
Industrial |
Panel Type |
a-Si TFT-LCD , LCM |
|
|
Reliability : |
Operating Temp. |
-30 ~ 85 °C |
Storage Temp. |
-40 ~ 85 °C |
RoHS State |
RoHS |
Vibration Level |
1.5G (14.7 m/s²) |
Specific Features : |
Wide Temperature,WLED Backlight,Life>=50 hours,With LED Driver,U/D,L/R Reverse,Matte |
AUO G057VCE-TH1 Mechanical Details
Pixel Features : |
Pixel Format |
640(RGB)×480, VGA |
Dot Pitch(mm) |
0.060×0.180 (H×V) |
Configuration |
RGB Vertical Stripe |
Pixel Pitch (mm) |
0.180×0.180 (H×V) [141PPI] |
Mechanical Size : |
Active Viewing |
115.2(H) × 86.4(V)mm |
Bezel Area(mm) |
118.2(H) × 89.4(V) |
Outline Dim.(mm) |
144(H) × 104.6(V) |
Depth(mm) |
12.3±0.5 |
Outline Features : |
Form Factor |
Flat Rectangle |
Orientation |
Landscape type |
Aspect Ratio |
4:3 (H:V) |
Shape Style |
|
Fixation :
|
Side mounting holes (4-Φ2.6), Rear mounting holes (4-Φ2.6) |
Other Detail : |
Mass |
TBD |
Surface |
Antiglare, Hard coating (3H) |
AUO G057VCE-TH1 Optical Details
Brightness |
Brightness |
450 cd/m² (Typ.) |
Contrast Ratio |
800:1 (Typ.) (Transmissive) |
Viewing Angle |
88/88/88/88(Typ.)(CR≥10) |
Optical Mode |
AMVA, Normally Black, Transmissivee |
Viewing Direction |
Symmetry |
Response Time |
13/12 (Typ.)(Tr/Td) |
Color Performance : |
Chromaticity |
Wx:0.313; Wy:0.329 |
Color Numbers |
262K (6-bit) |
Color Temperature |
6485K |
Uniformity |
1.255/1.39 (Typ./Max.)(5 points) |
1931 Color Gamut : |
NTSC Ratio |
71% |
sRGB |
94% coverage |
Adobe RGB |
72% coverage |
DCI-P3 |
74% coverage |
Rec.2020 |
53% coverage |
Remarks |
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
AUO G057VCE-TH1 Electronics Details
Frame Frequency : |
60Hz |
Reverse Scan : |
Yes (U/D, L/R) |
Time Controller (T-CON) : |
Embedded T-CON |
AUO G057VCE-TH1 Backlight Details
Back-light Features : |
Lamp Type |
WLED |
Amount |
- |
Life Time |
50K(Min.) (Hours) |
Replacement |
- |
Lamp Shape |
- |
Position |
Edge light type |
Interface Features : |
Position
|
- |
Physical Type |
Connector |
Interface Detail |
Brand |
Model |
Amount |
Pin Pitch |
Pin Amount |
Pin Assignment |
CviLux |
CI4205M2HRP-NH |
1 pcs |
1.25 mm |
5pins |
|
Backlight Driver : |
With LED Driver |
Backlight Driver : |
Input Current |
0.19±0.3A |
Input Voltage |
12.0±1.2V |
Consumption |
2.3W (Typ.) |
|
|
AUO G057VCE-TH1 Interface Details
Signal Electrical : |
Input Current |
145/175mA (Typ./Max.) |
Input Voltage |
3.3V (Typ.) |
Consumption
|
0.88/1.06W (Typ./Max.) |
Signal Interface |
Parallel RGB (1 ch, 6-bit) |
Logic Voltage |
0≤VIL≤0.3VCC; 0.7VCC≤VIH≤VCC |
Signal Interface : |
Brand |
Model |
Amount |
Pin Pitch |
Pin Amount |
Pin Assignment |
I-PEX |
20455-040E-76 |
1 pcs |
0.5mm |
40pins |
|
Innolux G057VCE-TH1 Packing Details
Package Box : |
Quantity |
Weight |
Box Size |
60 pcs / box |
11.65 Kgs |
500×400×330 mm (L×W×H) |
