• Technical Parameters

TIANMA P1500XGF1MB02 15.0inch LCD Panel

• 1. TIANMA P1500XGF1MB02 Application Details

  Basic Info :	Panel Brand	TIANMA	Panel Model	P1500XGF1MB02
  	Diagonal Size	15.0"	Application	Industrial
  	Panel Type	a-Si TFT-LCD , LCM	Model Alias	-
  Reliability :	Operating Temp.	-20 ~~70 °C	Storage Temp.	-30 ~~ 80 °C
  	RoHS State	RoHS	Vibration Rating
  Specific Features :	Hight Brightness，WLED Backlight,Life≥50K hours




  2. TIANMA P1500XGF1MB02 Mechanical Details

  Pixel Features :	Pixel Format	1024(RGB)×768 [XGA]	Dot Pitch	0.099×0.297 mm (H×V)
  	Configuration	RGB Vertical Stripe	Pixel Pitch	0.297×0.297 mm (H×V)  [85PPI]
  Mechanical Size :	Active Viewing	304.128(W)×228.096(H) mm	Overall Dim.	306.13×230.1 mm (H×V)
  	Bezel Opening	326.5×253.5 mm (H×V)	Outline Depth(mm)	9.5/12.3 (Typ./Max.) mm
  Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
  	Aspect Ratio	4:3(H:V)	Shape Style




  3. TIANMA P1500XGF1MB02 Optical Details

  Basic Information :	Brightness	600 cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
  	Viewing Angle	88/88/88/88 (Typ.)(CR≥10)	Optical Mode	SFT, Normally Black, Transmissive
  	Viewing Direction	Symmetry	Response Time	25 (Typ.)(Tr+Td) ms
  Color Performance :	Chromaticity	-	Color Numbers	16.7M (8-bit)




  4. TIANMA P1500XGF1MB02 Electronics Details

  Frame Frequency :

  60Hz




  5. TIANMA P1500XGF1MB02 Backlight Details

  Back-light Features:	Lamp Shape	WLED	Amount	-	Life Time	50K(Typ.) (Hours)
  	Replacement	-	Lamp Shape	-	Position	Edge light type




  6. TIANMA P1500XGF1MB02 Interface Details

  Signal Systerm :	Voltage Input	-	Current Input	-
  	Consumption	-	Signal Interface	LVDS (1 ch, 8-bit)
