Model No. | XH121062A-GDA-A1 |
Size | 12.1inch |
Product proportion | 16:10 |
Touch type | capacitive touch screen |
Touch point | 10 |
Outline Dimensional | 277.70*180.60mm |
View Area | 262.32*164.40mm |
Panel structure | G+G |
Temperature range | -20℃~+70℃ (30min) |
Humidity range | -30℃~+80℃ |
Working voltage | DC5.0V |
Linear equation | ≤2% |
Optical Characteristics | ≥87% |
Surface Hardness | ≥ 6H |
interface | USB/IIC |
IC | ILITEK 2511 |
FPC | COF |
Common outgoing lines of FPC with side width | Ultra narrow side, bottom left outlet |
以上参数仅供参考,实际还是要以产品规格书的数值为准确。
更多5~32“”电容 触摸屏产品目录选型列表:http://www.hzxuhong.com/productsnews/201908231019.html
