AUO G170HAN01.1 Application Details
| Basic Information : | Brand | AUO | Model | G170HAN01.1 |
| Type | a-Si TFT-LCD , LCM | Used For | Industrial |
| Screen Size | 17.0 inch | | |
Environment :
| Operating Temp. | -20 ~ 60 °C | Storage Temp. | -20 ~ 70 °C |
| RoHS | RoHS | Vibration | 1.5G (14.7 m/s²)
|
| Typical Features : | SRGB， WLED Backlight,Life>=50K hours,With LED Driver,Reverse I/F,Matte |
AUO G170HAN01.1 Mechanical Details
| Pixel Features : | Resolution | 1920(RGB)*1920 | Dot Pitch(mm) | 0.053*0.159 mm |
Pixel Format
R | RGB Vertical Stripe | Pixel Pitch(mm) | 0.159×0.159 mm [159PPI] |
Mechanical Size :
| Active Viewing | 305.28(W)*305.28(H) mm |
Overall Dim. | 325.01(W)*319.33(H) mm |
| Bezel Opening | - | Depth(mm) | 5.99/12.43 (Typ./Max.) mm |
Outline Features :
| Form Style | Flat Rectangle | Shape Style | |
| Aspect Ratio | 1:1 (H:V) | Orientation | Landscape type |
| Fixation : | Rear mounting holes (6-M3); Side mounting holes (4-M3) on left, right slugs |
| Other Spec : | Weight | 1.20Kgs (Max.) | Treatment | Antiglare, Hard coating (2H), Antireflection |
AUO G170HAN01.1 Optical Details
| Basic Information : | Luminance(cd/m²)
| 350 (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry | Response(ms) | 13/12 (Typ.)(Tr/Td) ms |
| Color Performance : | White Coordinate
|
Wx:0.313; Wy:0.329 | Display Colors | 16.7M (8-bit) |
Color Temperature
| 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(5points) |
| 1931 Color Gamut : | NTSC Ratio | 71% | sRGB | 98% coverage |
| Adobe RGB | 74% coverage | DCI-P3 | 74% coverage |
| Rec.2020 | 53% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
AUO G170HAN01.1 Electronics Details
| Frame Rate : | 60Hz |
| Reverse Scan : | No |
| Total Consumption : | 15.36W (Typ.) |
AUO G170HAN01.1 Interface Details
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 1.28A (Typ.) |
| Consumption | 15.36/16.9W (Typ./Max.) | | |
| Signal Type : | eDP (4 Lanes), eDP1.3 | Logic Voltage | - |
| Interface Features : | Position | Down middle of panel | | Type | Connector |
Interface Detail :
| Brand | Model | Pitch | Pins | Quantity | Pin Assignment |
| JAE |
HD1S040HA1 | 0.5mm | 40 pins | 1 pcs | |
AUO G170HAN01.1 Backlight Details
| Backlight Features : | Type | WLED | Quantity | 10S6P | Position | Edge light type |
| Replacement | - | Shape | 6 strings | Life Time | 50K(Min.) Hours |
| Interface Features : | Position | - | | Type | Included in signal interface |
| Backlight Driver : | With LED Driver |
AUO G170HAN01.1 Packing Details
| Package Box : | Quantity | Weight | Box Size |
| 10 pcs / box | 15 Kgs | 508*408*279 mm (L*W*H) |
-
Datasheet and Drawing Request
Contact us to request the current datasheet and mechanical drawing for G170HAN01.1. Please include your application and required quantity so we can confirm the applicable revision.
