1、AUO G185HAN01.4 Application Details
Basic Detail : | Manufacturer | AUO | Model Name | G185HAN01.4 |
Panel Type | a-Si TFT-LCD , LCM | |||
Panel Size | 18.5 inch | Designed For | Industrial | |
Maximum Ratings : | OP Temperature | -20 ~ 60 °C | ST Temperature | -20 ~ 60 °C |
Vibration Level | 1.5G (14.7 m/s²) | RoHS | RoHS | |
Features : | Srgb,Ultra High Brightness,WLED Backlight,Life>=50K hours,With LED Driver,Upside I/F,Matte | |||
2、AUO G185HAN01.4 Optical Details
Basic Information : | Luminance | 1800 cd/m² (Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
Good View at | Symmetry | Response Speed | 10/10 (Typ.)(Tr/Td) | |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | AHVA, Normally Black, Transmissive | |
Color Performance : | Chromaticity | Wx:0.299; Wy:0.315 | Operating Mode | 16.7M (8-bit) |
Color Temperature | 7502K | White Uniformity | 1.18/1.25 (Typ./Max.)(9 points) | |
1931 Color Gamut : | NTSC Ratio | 73% | sRGB | 99% coverage |
Adobe RGB | 76% coverage | DCI-P3 | 76% coverage | |
Rec.2020 | 55% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
3、AUO G185HAN01.4 Mechanical Details
Pixel Features : | Number of Pixel | 1920(RGB)×1080, FHD | Arrangement | RGB Vertical Stripe |
Dot Pitch(W×H) | 0.071×0.213 (H×V) | Pixel Pitch(W×H) | 0.213×0.213 (H×V) [119PPI] | |
Physical Size : | Active Viewing | 408.96(H) × 230.04(V) | Overall Dim. | 429.3(H) × 253.06(V) |
Bezel Opening | 412.56(H) × 233.64(V) | Overall Depth | 8.03/11.83 (Typ./Max.) | |
Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
Aspect Ratio(W:H) | 16:9 | Shape Style | ||
Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel | |||
Other Features : | Weight | 1.60Kgs (Typ.) | Treatment | Antiglare, Hard coating (3H), Antireflection |
4、AUO G185HAN01.4 Electronics Details
Frame Frequency : | 60Hz |
Reverse Scan : | No |
Total Consumption : | 52.5W (Max.) |
5、AUO G185HAN01.4 Backlight Details
Back-light Features : | Lamp Type | WLED | Quantity | 9S7P×2CN | Life Time | 50K(Min.) Hours | |||||||
Replacement | No | Lamp Shape | 7 strings × 2CN | Position | Edge light type (Top and Bottom) | ||||||||
Lamp Electrical : | Voltage Supply | 94mA (Typ.) | Current Supply | 27.0/30.6V (Typ./Max.) | |||||||||
Consumption | 35.53/40.27W (Typ./Max.) | ||||||||||||
Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver | |||||||
Interface Detail : | Brand | Model | Pitch | Pins | Quantity | Pin Configuration | |||||||
JST | SM08B-GHH-TB(HF) | 1.25 mm | 8 pins | 1 pcs | |||||||||
Driver Electrical : | Voltage Input | 21.8/24/26.4V (Min./Typ./Max.) | Current Input | 1.8/2A (Typ./Max.) | |||||||||
Consumption | 43.2/48W (Typ./Max.) | ||||||||||||
6、AUO G185HAN01.4 Interface Detail
Signal Systerm : | eDP (2 Lanes) | Logic Voltage | - | |||
Signal Electrical : | Voltage Input | 5.0V (Typ.) | Current Input | 0.6/0.9A (Typ./Max.) | ||
Consumption | 3.0/4.5W (Typ./Max.) | |||||
Interface Features : | Type | Connector | Position | Upper middle of panel | ||
Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
I-PEX | 20765-030E-11A | 0.5 mm | 30 pins | 1 pcs | ||
7、AUO G185HAN01.4 Carton Details
Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
8 pcs / box | 12.3Kgs | 520×365×360 mm |
Contact us to request the current datasheet and mechanical drawing for G185HAN01.4. Please include your application and required quantity so we can confirm the applicable revision.
