AUO G270QAN01.3 27 Inch QHD LCD Display – 98% DCI-P3 Professional AHVA Panel

Product Overview

The AUO G270QAN01.3 is a 27.0-inch industrial-grade TFT-LCD display module manufactured by AU Optronics (AUO). This panel delivers stunning Quad-HD resolution (2560×1440) in a 16:9 widescreen format, specifically engineered for professional design workstations, medical imaging equipment, video editing suites, and high-end industrial HMI applications requiring exceptional color accuracy and image clarity.

Key differentiator: With an impressive QHD resolution (2560×1440, 108 PPI) and 98% DCI-P3 wide color gamut—the professional standard for cinema and high-end displays—the G270QAN01.3 delivers approximately 77% more pixels than standard FHD panels and color accuracy that meets professional creative and medical imaging requirements.

Equipped with AHVA (AUO Advanced wide Viewing Angle) technology—similar to IPS—this display offers full 89/89/89/89° viewing angles with no grayscale inversion effect. The Normally Black mode provides deeper blacks and better contrast in dark environments. With 400 cd/m² brightness, 1600:1 contrast ratio, and 30,000-hour WLED backlight life, the G270QAN01.3 delivers exceptional visual performance for the most demanding professional applications.

Key Features

Key Advantages

1. QHD Resolution (2560×1440) – 77% More Pixels than FHD

The G270QAN01.3 delivers stunning Quad-HD resolution with 108 PPI pixel density—approximately 77% more pixels than standard FHD (1920×1080) displays. Key benefits include:

Exceptional image detail — perfect for graphic design, CAD/CAM, and medical imaging

More screen real estate — multitask with multiple windows side by side

Sharper text rendering — reduced eye strain during long work sessions

Crisp, detailed imagery — ideal for photo and video editing

2. 98% DCI-P3 Wide Color Gamut – Professional Color Accuracy

The G270QAN01.3 delivers an exceptional 98% DCI-P3 color gamut coverage—the professional standard for cinema, video editing, and high-end medical imaging. Key benefits include:

Cinema-grade color reproduction — accurate colors for video and film production

Medical imaging ready — meets the color accuracy requirements for diagnostic displays

Vibrant, lifelike colors — 16.7M colors (8-bit) for smooth gradations

6485K color temperature — neutral white balance for color-critical work

3. AHVA Wide Viewing Angle Technology + 1600:1 Contrast Ratio

The G270QAN01.5 incorporates AUO's proprietary AHVA technology (similar to IPS), delivering full 89-degree viewing angles in all directions and a 1600:1 contrast ratio—significantly higher than standard IPS panels. Key benefits include:

Excellent off-axis readability — no color shift or contrast loss from any angle

Superior color consistency — accurate colors across the entire viewing cone

No grayscale inversion — unlike conventional TN panels

Deep blacks and vivid colors — 1600:1 contrast ratio for enhanced image depth

Normally Black mode — better dark-room performance

4. 400 cd/m² Brightness for Professional Environments

With 400 cd/m² typical brightness, the G270QAN01.3 provides:

Excellent visibility in office and professional environments with standard lighting

Clear readability even in brightly lit medical and industrial settings

Reduced eye strain during extended viewing sessions

5. Fast Response Time (8/8 ms) – Smooth Motion

The 8/8 ms response time (Tr/Td) ensures:

Smooth motion display — ideal for video playback and interactive applications

Reduced ghosting — clear images during fast-moving content

Suitable for multimedia — video editing and animation work

6. LVDS Interface for Industrial Compatibility

The 4-channel LVDS (4 ch, 8-bit) interface with 92-pin connector offers:

High bandwidth — sufficient for QHD resolution at 60Hz

Stable signal transmission over longer distances

Wide compatibility with industrial controllers, embedded PCs, and SoCs

5.0V logic voltage — standard industrial levels

7. Anti-Glare Surface Treatment

The matte anti-glare surface provides:

Reduced reflections in office and industrial lighting conditions

Reduced eye strain during long work sessions

Enhanced readability in brightly lit environments

8. Industrial-Grade Reliability

30,000-hour WLED backlight life — suitable for continuous operation

1.5G vibration resistance (14.7 m/s²) — for transportation and industrial equipment

0°C ~ 50°C operating temperature — suitable for indoor professional environments

RoHS compliant — meets global environmental standards

In Production status — stable supply for ongoing production needs

Applications

The AUO G270QAN01.3 is designed for professional, medical, and industrial applications requiring exceptional resolution and color accuracy:

Quality Assurance

We supply 100% original AUO displays with strict quality control. Each unit undergoes comprehensive inspection to ensure:

No dead pixels or visual defects

Consistent brightness and color uniformity

Authentic AUO packaging and labeling

Full compliance with manufacturer specifications

Why Choose Us?

Factory Direct Pricing – Competitive rates for both sample and bulk orders

Global Shipping – Fast and reliable delivery worldwide

Technical Support – Expert assistance for integration and compatibility questions

Inventory Availability – Stable supply for ongoing production needs

Quality Guarantee – 100% tested before shipment

Customization Services — Touch panel upgrades, custom cables, optical bonding

Order Information

Comparison reference between AUO G270QAN01.3 and models of the same series/size:
