AUO G270QAN01.0 Application Details
| Basic Detail : | Manufacturer | AUO | Model Name | G270QAN01.0 |
| Panel Type | a-Si TFT-LCD , LCM | Another Name | |
| Panel Size | 27.0” | Designed For | Industrial |
| Maximum Ratings : | OP Temperature | 0 ~ 50 °C | ST Temperature | -20 ~ 60 °C |
| RoHS | RoHS | Vibration Level | 1.5G (14.7 m/s²) |
| Features : | DCI-P3,Adobe RGB,Srgb，WLED Backlight， Reverse I/F,Matte |
AUO G270QAN01.0 Optical Details
| Basic Information : | Luminance | 350cd/m²(Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
| Good View at | Symmetry | Response Speed | 8/8 (Typ.)(Tr/Td) (ms) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | AHVA, Normally Black, Transmissive |
| Color Performance : | Chromaticity | X:0.313; Y:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) |
| 1931 Color Gamlt : | NTSC Ratio | 106%
| sRGB
| 100% coverage
|
Adobe RGB
| 100% coverage | DCI-P3 | 95% coverage |
| Rec.2020 | 79% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
AUO G270QAN01.0 Mechanical Details
| Pixel Features : | Number of Pixel | 2560(RGB)*1440, Quad-HD | Arrangement | RGB Vertical Stripe |
| Dot Pitch(W*H) | 0.0777*0.2331 (H*V) | Pixel Pitch(mm) | 0.2331*0.2331 (H×V) [108PPI] |
| Physical Size : | Active Viewing(mm) | 596.74(H) *335.66(V) | Outline Dim.(mm) | 630(H) *368.2(V) |
| Bezel Area (mm) | 601.6(H) *340.15(V) | Outline Depth(mm) |
11.2/15.6 (Typ./Max.) |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type |
| Fixation : | Side mounting holes (4-M3) on left, right bezel |
| Other Features : | Weight | 3.15W (Typ.) | Treatment | Antiglare |
AUO G270QAN01.0 Electronics Details
| Refresh Rate : | 60Hz |
| Reverse Scan : | No |
| Total Consumption : | 31.5W (Typ.) |
AUO G270QAN01.0 Interface Detail
| Signal Electrical : | Voltage Supply | 5.0V (Typ.)
| Current Supply | 1.1/1.32A (Typ./Max.) |
| Consumption | 5.5/6.6W (Typ./Max.) | Signal Interface | LVDS (4ch, 8-bit) |
| Interface Features : | Position | Rear | Type | Connector |
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-RE51S-HF | 1 pcs | 51pins | 0.5mm | |
AUO G270QAN01.0 Backlight Details
| Lamp Features : | Lamp Type | WLED | Quantity | - | Position | Edge light type |
| Exchange |
- | Lamp Shape | 4 strings | Lamp Life | 30K(Min.) (Hours) |
| Lamp Electrical : | Voltage Supply | 54/61.2V (Typ./Max.) | Current Supply | 108/120mA (Typ./Max.)
|
Consumption
| 26/29.4W (Typ./Max.) |
| Interface Features : | Position | Rear | Physical Type |
Connector |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment |
| E&T | 3707K-S06N-21R | 1.0mm | 6 pins | 1 pcs | BLE-6PINS-CCAACC |
| Backlight Driver : | No |
| Driver Electrical : | Input Current | 0.47/0.56A (Typ./Max.) | Input Voltage | 12.0V (Typ.) |
| Consumption | 5.7/6.72W (Typ./Max.) |
AUO G270QAN01.0 Packing Details
| Package Box : | Quantity | Weight | Box Size |
| 8pcs / box | 28.6 Kgs | 735*258*480 mm (L*W*H) |
-
Datasheet and Drawing Request
Contact us to request the current datasheet and mechanical drawing for G270QAN01.0. Please include your application and required quantity so we can confirm the applicable revision.
