AUO G270ZAN01.7 Application Details
| Basic Information : | Brand | AUO | Model | G270ZAN01.7 |
| Type | a-Si TFT-LCD , LCM | Used For | Industrial，Medical Imaging |
| Screen Size | 27.0 inch | | |
| Environment : | Storage Temp. | -20 ~ 60°C | Operating Temp. | 0 ~ 50 °C |
| RoHS | RoHS | | |
| Typical Features : | WLED Backlight，Life>=50K hours |
AUO G270ZAN01.7 Mechanical Details
| Pixel Features : | Resolution | 3840(RGB)*2160, UHD | Dot Pitch(mm) | 0.05175*0.15525 (H*V) |
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.15525*0.15525 (H*V) [163PPI] |
| Mechanical Size : | Active Area(mm) | 596.16(H) *335.14(V) | Bezel Area(mm) | - |
| Outline Features : | Form Style | Flat Rectangle | Shape Style | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type |
AUO G270ZAN01.7 Optical Details
Basic Information :
| Luminance(cd/m²) | 500 (Typ.) | Contrast Ratio | 1450:1 (Typ.) (Transmissive) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry | Response(ms) | 16 (Typ.)(Tr+Td) |
| Color Performance : | White Coordinate | Wx:0.313; Wy:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.18/1.25 (Typ./Max.)(9 points) |
AUO G270ZAN01.7 Electronics Details
| Frame Rate : | 60Hz |
| Reverse Scan : | No |
AUO G270ZAN01.7 Interface Detail
| Signal Type : | eDP | Logic Voltage | - |
AUO G270ZAN01.7 Backlight Details
| Backlight Features : | Type | WLED | Quantity | - | Position | Edge light type |
| Replacement | - | Shape | - | Life Time | 50K(Min.) (Hours) |
| Backlight Driver : | No |
-
Datasheet and Drawing Request
Contact us to request the current datasheet and mechanical drawing for G270ZAN01.7. Please include your application and required quantity so we can confirm the applicable revision.
Request G270ZAN01.7 Datasheet
