1、AUO G057QAN01.0 Application Details
Basic Info : | Panel Brand | AUO | Panel Model | G057QAN01.0 |
Diagonal Size | 5.7" | Application | Industrial |
Panel Type | a-Si TFT-LCD , LCM |
|
|
Reliability : | Operating Temp. | -30 ~ 85 °C | Storage Temp. |
-30 ~ 85 °C |
RoHS State | RoHS | Vibration Rating | 1.5G (14.7 m/s²) |
Specific Features : | Wide Temperature，WLED Backlight，Life≥70K hours，With LED Driver，U/D,L/R Reverse，Matte |
2、AUO G057QAN01.0 Mechanical Details
Pixel Features : | Pixel Format | 320(RGB)×240, QVGA | Dot Pitch |
0.12×0.36 mm (H×V) |
Configuration | RGB Vertical Stripe | Pixel Pitch | 0.36×0.36 mm (H×V) [70PPI] |
Mechanical Size : | Display Area | 115.2×86.4 mm (H×V) | Bezel Area | 118.2×86.4 mm (H×V) |
Outline Dim. | 144×104.6 mm (H×V) |
Outline Depth | 12.8 (Max.) mm |
Outline Features : | Form Factor | Flat Rectangle | Orientation | - |
Aspect Ratio | 4:3 (H:V) | Shape Style | - |
Holes & Brackets : | Rear mounting holes |
Other Features : |
Weight |
150/165g (Typ./Max.) | Surface | Antiglare, Hard coating (3H) |
3、AUO G057QAN01.0 Optical Details
Basic Information : | Brightness | 500 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Optical Mode | VAHVA, Normally Black, Transmissive |
Viewing Direction | Symmetry | Response Time |
15/10 (Typ.)(Tr/Td) ms |
Color Performance : | Chromaticity |
Wx:0.313; Wy:0.329 |
Color Numbers | 262K (6-bit) |
Color Temperature
| 6485K | Uniformity | - |
4、AUO G057QAN01.0 Electronics Details
Frame Frequency : | 60Hz |
Reverse Scan : | Yes (U/D, L/R) |
Power Consumption : | 1.42W (Typ.) |
5、AUO G057QAN01.0 Backlight Details
Back-light Features : | Lamp Type | WLED | Amount | - |
Life Time | 70K(Min.) (Hours) |
Replacement | - | Lamp Shape | - | Position | Edge light type |
Lamp Electrical : | Voltage Input | 22.4/23.6/24.8V (Min./Typ./Max.) |
Current Input | 50mA (Typ.) |
Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
Interface Detail : | Brand | Model |
Pin Pitch | Pins | Amount | Configuration |
CviLux | CI1106M1HR0-NH | 1.0 mm | 6pins | 1pcs |
|
Driver Electrical : | Voltage Input |
9.0/12.0/20.0V (Min./Typ./Max.)
| Current Input | 0.1/0.11A (Typ./Max.) |
Consumption | 1.33/1.39W (Typ./Max.) |
6、AUO G057QAN01.0 Interface Detail
Signal Systerm : | CMOS (1 ch, 6-bit) | Logic Voltage | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD |
Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 27/30mA (Typ./Max.) |
Consumption | 0.09/0.10W (Typ./Max.) |
Interface Features : | Type | Connector |
| Position | - |
Connector Detail : | Brand | Model | Pin Pitch |
Pins | Amount | Configuration |
STARCONN | 089H33-000100-G2-R | 0.5 mm | 33 pins | 1 pcs |
|
7、AUO G057QAN01.0 Carton Details
Package Type | Pcs/Package | Box/Package | Package LWH (mm) | G.W (kgs) | Volume (m³) |
Carton | 60 | 1 | 520×340×250 | 12.95 | 0.0442 |
-
Datasheet and Drawing Request
Contact us to request the current datasheet and mechanical drawing for G057QAN01.0. Please include your application and required quantity so we can confirm the applicable revision.
