AUO G080UAN02.1 Application Details
| Basic Information : | Brand | AUO | Model | G240HW01 V1 |
| Type | a-Si TFT-LCD , LCM | Used For | Industrial |
| Screen Size | 8.0inch | | |
Environment :
| Storage Temp. | -20 ~ 60 °C | Operating Temp. | 0 ~ 50 °C |
| RoHS | RoHS | Vibration | 1.5G (14.7 m/s²) |
| Typical Features : | Portrait type,WLED Backlight，Glossy |
AUO G240HW01 V1 Mechanical Details
| Pixel Features : | Resolution | 1200(RGB)*1920, WUXGA | Dot Pitch(mm) | 0.0299*0.0897 mm (H*V) |
Pixel Format
R | RGB Vertical Stripe | Pixel Pitch(mm) | 0.0897*0.0897 mm (H*V) [283PPI] |
Mechanical Size :
| Active Viewing (mm) | 107.64*172.224 (H*V) |
Bezel Area(mm) | - |
| Outline Dim.(mm) | 114.6*184.125 (H*V) | Depth(mm) | 2.3/3.95 (Max.) mm |
Outline Features :
| Form Style | Flat Rectangle | Shape Style | |
| Aspect Ratio | 10:16 (H:V) | Orientation | Portrait type |
| Fixation : | Without |
| Other Spec : | Weight |
- | Treatment | Glare (Haze 0%) |
AUO G240HW01 V1 Optical Details
| Basic Information : | Luminance(cd/m²) | 390 (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | AMVA, Normally Black, Transmissive |
| Best View on | Symmetry | Response(ms) | 25 (Typ.)(Tr+Tf) ms |
| Color Performance : | White Coordinate
|
Wx:0.300; Wy:0.320 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 7351K | White Uniformity | - |
AUO G240HW01 V1 Electronics Details
| Frame Rate : | 60Hz |
| Reverse Scan : | No |
AUO G240HW01 V1 Interface Details
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply
| 150mA (Max.) |
| Consumption | 0.5W (Max.) | | |
| Signal Type : | MIPI (4 data lanes) | Logic Voltage | - |
| Interface Features : | Position | - | | Type | Connector |
Interface Detail :
| Brand | Model | Pitch | Pins | Quantity | Pin Assignment |
| I-PEX | 20718-051E-01 | 0.3mm | 51 pins | 1 pcs |
|
AUO G240HW01 V1 Backlight Details
| Backlight Features : | Type | WLED | Quantity | 8S4P | Position | Edge light type |
| Replacement | - | Shape | 4strings | Life Time | 15K(Min.) Hours |
| Interface Features : | Position | - | Type | Included in signal interface | Backlight Driver : | No |
| Driver Electrical : | Voltage Supply | 23.04/24.8V (Typ./Max.) | Current Supply | 20mA (Typ.) |
| Consumption | 1.38/1.49W (Typ./Max.) | |
AUO G240HW01 V1 Packing Details
| Package Box : | Quantity | Weight | Box Size (L*W*H) |
| 66pcs / box | 10.2 Kgs | 520*340*250 mm |
-
Datasheet and Drawing Request
Contact us to request the current datasheet and mechanical drawing for G080UAN02.1. Please include your application and required quantity so we can confirm the applicable revision.
